Scene 1

Scene 2

Scene 3

Scene 4

Gel casting tray Sample comb Electrophoresis chamber & power supply Agarose  (creating pores)  Electrophoresis buffer  [1X  TAE  ( Tris  acetate EDTA) or 1X TBE( Tris  borate EDTA)] Loading buffer  (containing  glycerol  &  bromophenol blue ) Ethidium bromide  (intercalates between bases of nucleic acids) UV  transilluminator (to visualize nucleic acid stained with ethidium bromide)

Scene 5

Procedures for 1 % agarose gel preparation

Agarose (1 g) + Buffer (100 ml)  Leave to cool + Eth Br Pour in tray Remove comb after polymerization Loading samples and electrophoresis Visualize under UV transilluminator

Scene 6

Scene 7

Scene 8

Scene 9

http://bristoluniversityfacultyofscience.blogspot.com/2010_06_01_archive.html http://oceanexplorer.noaa.gov/explorations/03bio/background/molecular/media/gel_plate.html

DNA separation by  Agarose  gel electrophoresis

Scene 10

As DNA molecules are negatively charged (because of phosphate groups), negative pole is connected near samples

Scene 11

Scene 12

Scene 13

Scene 14

Scene 15

Scene 16

Scene 17

100bpLadderDNAM±r
(1 m bp-2000bp)
bp
1500
100
ng/loul
Real Biotech Corportion

Scene 18

Scene 19

G:\kolya\fourth year genetics\DNA isolation 23-9-2012.tif

Scene 20

Effect of increasing Agarose concentration

Higher concentrations of agarose facilities separation of small DNAs, while low agarose concentrations allow resolution of larger DNAs.

Scene 21

Scene 22

Scene 23

Scene 24

DNA concentration  α  amount of absorbance 1 absorbent (O.D.) at 260 nm = 50  ng /µl (µg/ml) of  d.s . DNA 					       = 33  ng /µl  s.s . DNA 					      = 40  ng /µl RNA Dilution factor = total volume/added volume of DNA  DNA concentration of sample = A260 x 50 x dilution factor

Scene 25

A260: max absorbance for nucleic acid A280: max absorbance for proteins DNA purity= A260/A280= 1.7-2 If less, therefore protein contamination If more, therefore RNA contamination

Scene 26

10 µl were taken from a sample to measure its concentration and purity; 	A260 nm= 0.122 		&     A280= 0.093 	a 3 ml  cuvette  was used and distilled water was used as a blank.  Calculate DNA concentration in the provided sample per µl.  Answer?? Sample  concn = 0.122x50x(3000/10)= 1830  ng /µl Purity= A260/A280= 0.122/0.093= 1.3

Scene 27

Diphenylalanine , binds with DNA, (blue dye) at  = 600 nm Standard curve is used.

0.8
0.6
0.4
02
1500
2000
Conæntration [ng/pL]

Absorbance of sample of unknown concentration

Scene 28

How to make a standard curve to measure DNA concentration

Data for known DNA concentrations are used to make the standard curve, plotting concentration on the X axis, and the absorbance on the Y axis. The same assay is then performed with samples of unknown concentration.  To analyze the data, one locates the measurement on the Y-axis that corresponds to the assay measurement of the unknown substance and follows a line to intersect the standard curve. The corresponding value on the X-axis is the concentration of substance in the unknown sample.

Scene 29

Scene 30

https://www.youtube.com/watch?v=vtxb6Tr8Y3s https://www.youtube.com/watch?v=EZjNuqSEPbY https://www.youtube.com/watch?v=vq759wKCCUQ https://www.youtube.com/watch?v=dedL1Br3Nos
