ISOKINETIC (CYBEX) GAIT & MOTION LAB

ISOKINETIC (CYBEX) GAIT & MOTION LAB. Departemen Ilmu Kedokteran Fisik dan Rehabilitasi FK UNAIR – RSUD Dr. SOETOMO.

Isokinetic Dynamometer (CYBEX). Human Cybex Norm 770 | Department of Health and Physical Education.

Cybex. Unit peralatan yang digunakan untuk : Testing : Mengukur kekuatan otot (torsi) Evaluation : Mengevaluasi kekuatan otot pasca rehabilitasi / monitoring..

Pilihan Test. Isokinetic Isometric CPM (Continues Passive Motion) Active Assist Isotonic Proprioceptive.

Isokinetic Kontraksi otot memendek (concentric) atau memanjang (eccentric) Ditentukan oleh kecepatan sudut ( derajat / detik ).

Isometric Panjang otot tetap , tidak ada gerakan sendi Dapat ditentukan disudut tertentu CPM (continues passive motion) Gerakan sepenuhnya dari mesin, kecepatan sudut dapat diatur sesuai kebutuhan.

Active Assist Gerakan sesuai luas gerak sendi , kontraksi otot dibantu oleh mesin . Isotonic Gerakan otot memendek dan memanjang, ada gerakan sendi, tidak dibatasi kecepatan..

Proprioceptive Mengukur proprioceptive sendi : Joint Position Sense Time to Detect Passive Motion.

Kapan Pasien memerlukan isokinetic test Evaluasi pasca operasi (ACL/PCL reconstruction, Rotator cuff, dll) Persyaratan return to sport / play Evaluasi propriosepsi Evaluasi kekuatan otot (torque).

Gait & Motion Laboratory.

Gait and Motion Laboratory. A facility built to the study of human movement for the purpose of understanding complex gait and motion abnormalities in children and adults and applying this knowledge in novel ways to prescribe and evaluate mobility related interventions..

Instrumented Gait Analysis. Standard Gait Analysis 2D Kinetic Kinematic Advance Gait Analysis 3D Kinetic Kinematic EMG.

2-Dimensional Gait Analysis. s»gge.

3-Dimensional Gait Analysis. Related image. Image result for 3D gait lab.

Motion and Gait Laboratory RSUD Dr. Soetomo. Software : CMAX (Clinical Motion Analysis Xystem) Peak Motus 2000 Equipment : 2 Basler Camera 2 Force Plate (AMTI) 1 Unit PC Dell i7 1 Unit Power Unit Surface EMG (8 Channels) + 1 PC Pentium.

Referring Cases. Pre operative evaluation Post operative evaluation Prosthesis evaluation (AKP, BKP) Orthotic evaluation (AFO, Shoes) Gait pathology (Stroke, Polio, Spina Bifida, CP, HNP, CIDP, Drop Foot, SCI, Knee OA, etc).

Clinical Gait Analysis. The process by which quantitative information is collected to aid in understanding the etiology of gait abnormalities and in treatment decision-making. This process is facilitated through the use of technology such as specialized, computer-interfaced video cameras to measure patient motion, electrodes placed on the surface of the skin to appreciate muscle activity, and force platforms imbedded in a walkway to monitor the forces and torques produced between the ambulatory patient and the ground..

When the patients refer to the Gait Lab ?. Gait pre operative evaluation Gait post operative evaluation Doubt result in visual gait analysis Need information about GRF, Moments, EMG during gait Need information about orthoses or prosthesis forces during gait.

. abstract. abstract.

abstract. .

. .

abstract. abstract. abstract. . . abstract.

Send the Patient to Gait Lab. Clinical request ? Planning for surgery, need information about knee flexion during swing and stance phase. Evaluate forces on the new AFO. Uncomforted gait, can gait improve ? Limping gait and tend to exhausted Balance disturbance during gait .....

Motion Analysis. 148-80. Oz-sn. Swimmer.

Referring Cases (Motion Analysis). Motion evaluation after injury (Post Reconstruction ACL/PCL) Functional motion evaluation (Ground Reaction Force, Kinematic analysis) Human motion (Need kinematic and kinetic evaluation).

Fenching Athlete. - Left - - 01 4,354 N Fx -36,706 N Fy 600 400 200.

Tennis Table Athlete. tepping 2 side right dorsal dorsal ng 2 side right 600 400 200 3 4 Stepping 2 side right left left 7 8 56.714 N Fz —109.783 N Fy 45.690 N Fx 9.
